The 5750 Linear Scorcher uses a floating head to follow the contours of each sample, allowing finished products to be tested. With virtually no limit on sample size or shape, the Linear Scorcher 5750 is ideal for testing consumer products, automotive components, painted parts, printed graphics, optical products, rubber, leather, textiles and for use in testing laboratories.

Characteristics:
With adjustable stroke length, speed, load and a wide selection of Taber accessories, the 5750 Linear Burner allows you to customize test parameters to your exact needs. With accessories, the linear abrasive can be used to perform scratches, coin scratches, crockmeter, rubs, pencil hardness scratches, clip marks, chemical rubs, wire scratches and other tests. An optional sample table provides additional flexibility for securing samples.

He Linear Scorcher 5750 Ê wears with Wearaser. The size and shape of a pencil eraser, the Wearaser uses the same high-quality Taber abrasive media found in Taber's world-famous wheels, so you're assured of consistent test results.

* Eleven stroke lengths (0.2" to 4.0").
* Variable stroke speed from 2 to 75 cycles per minute.
*Preset running speed buttons for 2, 15, 25, 30, 40, 60 cycles per minute.
* Variable load from 350 to 2100 grams with optional weight plates.
*Stainless steel Wearaser tweezer for use with vitrified or heavy duty Wearasers.
* Laser alignment guide.
* Programmable to 999,999 cycles.
*CE marked 115V/230V switchable.

Includes:
* Wearaser caliper and knurled shaft (350 grams).
* Discs weighing 250 grams (3 each).
*Wearasers CS-10 (pkg/10).
* Wearasers H-18 (pkg/5).
* Power cables (115V and 230V).
* Hex L -wrench tool.
* Wearaser depth gauge tool.
* S-14 grinding strips (package/50).
* Hand brush
